Magnesium Oxide Board
Magnesium Oxide Board(MgO Board)is a new type of non-combustible decorative material made from high-purity active magnesium oxide,magnesium chloride/magnesium sulfate,reinforced with alkali-resistant fiberglass mesh,and blended with lightweight fillers such as perlite and plant fibers.
Phone ：+86 15563544445
WhatsApp ：+86 15563544445
Email ：wsun92686@gmail.com
Message
product description

Product Description

Magnesium Oxide Board(MgO Board)is a new type of non-combustible decorative material made from high-purity active magnesium oxide,magnesium chloride/magnesium sulfate,reinforced with alkali-resistant fiberglass mesh,and blended with lightweight fillers such as perlite and plant fibers.It combines the fire resistance and water resistance of inorganic panels with the flexibility and workability of wood,making it an ideal replacement for traditional gypsum boards,cement fiber boards,and plywood.

Product Specifications

ItemSpecification
Standard Sizes1220×2440mm,1200×2400mm,2440×1830mm,915×2150mm
Custom SizesLength 2400-3050mm,Width 900-1220mm
Thickness3mm,4mm,5mm,6mm,8mm,9mm,10mm,12mm,15mm,18mm,20mm
ColorsWhite,Grey,Blue,Green(customizable)
Edge TypesT&G,Square Edge,Tapered Edge,Beveled Edge
Apparent Density0.8-1.2 g/cm³
Fire RatingA1 Non-combustible(GB8624/EN13501)
Fire Resistance≥3 hours(6mm board+lightweight partition system)
Bending StrengthLongitudinal≥13MPa,Transverse≥8MPa
Water Absorption≤20%-28%
Sound Insulation≥42dB(9mm board+framing system)
Advantages and Applications

Key Advantages

A1 Class Fireproof&Non-Combustible:Zero flame duration,non-combustible at 800°C,no flame at 1200°C.Meets the highest fire rating A1.Fire resistance up to 3+hours when used with lightweight partition systems.

Excellent Water&Moisture Resistance:No deformation or swelling after long-term water immersion.Dry-wet deformation rate as low as 0.26%with low water absorption.Ideal for basements,mines,and other humid environments.

Lightweight&High Strength:Apparent density of 0.8-1.2 g/cm³reduces wall weight by over 60%.Bending strength≥13MPa(longitudinal)and≥8MPa(transverse).Excellent impact resistance with balanced rigidity and toughness.

Eco-Friendly&Green:100%asbestos-free,formaldehyde-free,and non-radioactive.Emits no toxic smoke when exposed to fire.

Easy to Process&Install:Can be nailed,sawed,planed,drilled,and glued.Excellent surface coloring properties—can be painted,laminated,or tiled directly.No special tools required for cutting and installation.

Sound&Thermal Insulation:6mm board provides 29dB sound insulation;9mm board with framing system achieves 42dB+.Low thermal conductivity for superior heat insulation.

Pest&Mold Resistant:Inedible to termites and other pests.Does not support mold growth due to non-hygroscopic properties.

Applications

MgO Board is widely used in building and decoration projects:

Interior Partition Walls:Lightweight wall systems for residential,hotels,offices

Ceiling Systems:Suspended ceilings for commercial spaces,schools,hospitals,airports

Interior&Exterior Wall Cladding:Decorative and protective wall panels

Flooring Substrates:High-strength floor covering materials

Fire Door Cores:Core material for fire-rated doors

Tile Backer Boards:Substrate for tiling in bathrooms and kitchens

Furniture Substrates:Replacement for plywood in furniture manufacturing

Composite Insulation Panels:Combined with various insulation materials

Customized sizes and specifications are available according to customer requirements,project needs and destination market preferences.

Export Packaging and Consulting

Packing and Loading

MgO Board is packed with export standard pallet packing.Each pallet can be protected with plastic film,carton or plywood cover,and fixed with steel or plastic straps.Good packing helps reduce damage during handling,loading and long-distance transportation.

Regular container loading options include 20GP and 40HQ.Loading quantity depends on thickness,size,density and packing method.

Send Your Inquiry

Share your MgO Board requirements with us,and our team will recommend suitable specifications according to your application,market and project needs.

For a more accurate quotation,you can include the following details in your inquiry:

Thickness:3mm,4mm,5mm,6mm,8mm,9mm,10mm,12mm,15mm,18mm,20mm or customized thickness

Size:1220×2440mm,1200×2400mm or customized size

Color:White,Grey,Blue,Green or customized color

Edge Type:T&G,Square Edge,Tapered Edge,Beveled Edge or customized edge type

Application:Interior partition,ceiling,wall cladding,flooring substrate,fire door core,tile backer or other use

Order Quantity:Pieces,cubic meters,pallets or container quantity

Destination Market:Destination country or port for packing and loading reference

We will provide product details,packing suggestions and quotation support as soon as possible.

Product Applications
  • 低密度轻质硫氧化镁医院净化板_-_MOS_机制面板和净化夹芯板_cleanroomequipment.en.made-in-china.com_20260626022544_region
  • 用于室内装饰的HPLPVC复合氧化镁板_-_HPL复合氧化镁板和PVC复合氧化镁_weiranbuild.en.made-in-china.com_20260626031721_region
  • 28毫米耐磨货运集装箱胶合板地板_-_集装箱地板和集装箱胶合板地板_wfsuntop.en.made-in-china.com_20260626031921_region
  • 厂家直销价整屋集装箱实木复合橡木亮面木地板_-_地板砖和建筑材料_sdluhuan.en.made-in-china.com_20260626032102_region
  • 厂家直销价整屋集装箱实木复合橡木亮面木地板_-_地板砖和建筑材料_sdluhuan.en.made-in-china.com_20260626032126_region
  • 出口级大理石纹理地坪漆，自流平车间地坪漆，户外耐磨环氧彩色砂地坪漆_-_环氧彩色_qdenze2006.en.made-in-china.com_20260626062212_region
  • 出口级大理石纹理地坪漆，自流平车间地坪漆，户外耐磨环氧彩色砂地坪漆_-_环氧彩色_qdenze2006.en.made-in-china.com_20260626062424_region
  • 出口级大理石纹理地坪漆，自流平车间地坪漆，户外耐磨环氧彩色砂地坪漆_-_环氧彩色_qdenze2006.en.made-in-china.com_20260626062524_region
  • 出口级大理石纹理地坪漆，自流平车间地坪漆，户外耐磨环氧彩色砂地坪漆_-_环氧彩色_qdenze2006.en.made-in-china.com_20260626062539_region
  • 环氧彩色砂面地坪漆，大理石纹理室内住宅防水防滑水泥地坪漆，自流平地坪漆_-_20_qdenze2006.en.made-in-china.com_20260626063146_region
FAQ
Q：

What types of paints/coatings do you offer,and which substrates are they suitable for?

A：
We provide comprehensive coating systems for various building boards,including water-based eco-coatings,fire-retardant coatings,and anticorrosion coatings.They can be customised according to different substrates(fibre cement,magnesium oxide,calcium silicate,etc.)and application environments(indoor,outdoor,humid conditions).
Q：

What are the features of Container Flooring HPL?

A：
HPL(High-Pressure Laminate)container flooring is made from multiple layers of kraft paper impregnated with thermosetting resin and combined with a decorative layer.It offers high abrasion resistance and high scratch resistance.Typical construction is plywood substrate with HPL overlay,thickness range 6-35mm,and sizes can be customised.
Q：

What is the fire rating and fire resistance limit of Magnesium Oxide Board?

A：
Magnesium Oxide Board achieves the highest non-combustible A1grade–it does not burn at 800°C,shows no flame at 1200°C,and has an ignition point as high as 2700°C.When used with quality steel framing,the partition system can achieve a fire resistance of over 3 hours.A 6mm board provides sound insulation of approximately 29dB.
Q：

What are the unique advantages of Fiber Reinforced Calcium Silicate Board?

A：
These boards are cured by steam or high-pressure steam to form a stable structure mainly composed of tobermorite crystals.They are lightweight,high-strength,fireproof,moisture-proof,heat-insulating,and have low deformation rates.Thicknesses of 5-12mm are suitable for interior partition walls and ceilings,while 18mm+boards are used for loft flooring and raised access floors for underfloor heating systems.
Q：

What specifications and densities are available for Fiber Cement Board?

A：
Standard sizes are 2000-2440mm in length and 1000-1220mm in width,with common thicknesses of 4-12mm(customisable from 2.5mm to 90mm in China).They are classified into high,medium,and low density–higher density and thicker boards provide better thermal and acoustic insulation.Products meet JC/T 412.1-2018 and JC/T 412.2-2018,with non-combustible A-grade,corrosion resistance,and electrical insulation properties.
Q：

What is the difference between Magnesium Oxysulfate Board and ordinary Magnesium Oxide Board?

A：
Magnesium Oxysulfate Board uses magnesium sulfate as the cementitious material,while traditional Magnesium Oxide Board(chloride-type)uses magnesium chloride.The biggest advantage of Magnesium Oxysulfate Board is that it does not absorb moisture or cause halogenation–chloride ions in chloride-type boards are hydrophilic and can attract moisture from the air under humid conditions,causing surface droplets and corrosion to metal.The sulfate type avoids these issues,offering excellent fire resistance,light weight,corrosion resistance,high dimensional stability,and low alkalinity.The industry standard for this product was finalised in 2021.
Q：

What is the substrate of Inorganic Pre-coated Board,and how ecofriendly is it?

A：
Inorganic Pre-coated Board is based on 100%asbestos-free calcium silicate board,which is then surface-treated and precision-coated.It contains no formaldehyde,no asbestos,and no radioactive elements,making it a green building material.In 2020,it was recognised as a Green Design Product by the Ministry of Industry and Information Technology(5th batch).
