High Pressure Laminate
High Pressure Laminate(HPL),also known as decorative laminate or fireproof board,is a decorative material made from decorative paper and multiple layers of kraft paper impregnated with thermosetting resins(melamine resin for surface layers,phenolic resin for core layers),then consolidated under high temperature(approx.150°C)and high pressure(not less than 7MPa).
Phone ：+86 15563544445
WhatsApp ：+86 15563544445
Email ：wsun92686@gmail.com
Message
product description

Product Description

High Pressure Laminate(HPL),also known as decorative laminate or fireproof board,is a decorative material made from decorative paper and multiple layers of kraft paper impregnated with thermosetting resins(melamine resin for surface layers,phenolic resin for core layers),then consolidated under high temperature(approx.150°C)and high pressure(not less than 7MPa).HPL is considered one of the most durable decorative surface materials available.Based on thickness,HPL is divided into thin HPL(<2mm,intended for bonding to supporting substrates)and compact HPL(≥2mm,also known as solid grade laminate,can be used as a standalone structural material).

Product Specifications

ItemSpecification
Standard Sizes1220×2440mm,1220×3050mm,1525×3050mm
Other Sizes2440×1830mm,1830×915mm(customizable)
Thin HPL Thickness0.6mm,0.7mm,0.8mm,0.9mm,1.0mm
Compact HPL Thickness2mm,3mm,4mm,5mm,6mm,8mm,10mm,12mm,15mm,18mm,20mm,25mm
Density≥1350 kg/m³
Water Absorption≤0.1%-0.6%
Bending Strength≥156MPa
Modulus of Elasticity≥13900MPa
Surface FinishesGloss,Matte,Super Matte,Textured,Metallic
Patterns/ColorsWood grain,Stone texture,Solid colors,Metallic,Abstract patterns(customizable)
Advantages and Applications

Key Advantages

Fire Retardant:HPL is difficult to ignite and only burns in the presence of open flames;self-extinguishes when the flame source is removed.Fire rating up to B-s2,d0 to C-s2,d0(EN 13501-1).Thick products(≥6mm)can achieve fire-resistant quality.

Excellent Water&Moisture Resistance:Ultra-low water absorption(≤0.1%-0.6%).High-performance resin ensures perfect fusion between layers under high temperature and pressure.Does not swell,mold,or rot.

Wear&Scratch Resistant:Melamine resin surface provides high surface hardness and abrasion resistance.Withstands high-frequency usage in demanding environments.

Chemical Resistant:Resistant to acids,alkalis,and stains;stain resistance≥Level 4.Ideal for laboratory countertops,kitchens,and other chemical-exposed environments.

Impact Resistant:Compact HPL(solid grade laminate)is sturdy and impact-resistant.Can be used as a structural material without additional substrate.

Eco-Friendly:E0 grade options available—formaldehyde-free and non-radioactive.

Rich Colors&Patterns:Wide variety of surface colors and textures,capable of simulating wood grain,stone,metal,and more.Meets diverse interior design requirements.

Easy to Clean&Maintain:Smooth,dense surface resists dirt and is easy to clean.

Easy to Process:Compact HPL can be drilled,cut,and chamfered using standard carbon alloy steel tools.

Applications

HPL is widely used in building and decoration projects:

Thin HPL(<2mm,surfacing material):

Furniture Surfacing:Cabinets,wardrobes,office furniture,door panels

Interior Walls:Wainscoting,feature walls,partition decoration

Ceiling Systems:Suspended ceilings for commercial spaces and offices

Countertops:Kitchen and laboratory worktop surfacing

Compact HPL(≥2mm,standalone use):

Toilet Partitions:Public restroom and changing room dividers

Laboratory Worktops:School and research institution lab benches

Interior Wall Cladding:Hospitals,schools,hotels,airports,and other public spaces

Public Transportation:Subway and railway station interiors

Marine Interiors:Ship cabin partitions,corridors,doors,wall and ceiling coverings

Exterior Applications:Facade cladding(exterior-grade products meeting EN 438-6 required)

Customized sizes,thicknesses,and patterns are available according to customer requirements,project needs and destination market preferences.

Export Packaging and Consulting

Packing and Loading

HPL panels are packed with export standard pallet packing.Thin HPL panels are wrapped with plastic film for moisture protection and protected with carton or plywood covers;compact HPL panels are wrapped with plastic film and fixed with steel or plastic straps.Good packing helps reduce damage during handling,loading and long-distance transportation.

Regular container loading options include 20GP and 40HQ.Loading quantity depends on thickness,size,density and packing method.

Send Your Inquiry

Share your HPL requirements with us,and our team will recommend suitable specifications according to your application,market and project needs.

For a more accurate quotation,you can include the following details in your inquiry:

Type:Thin HPL(surfacing material)or Compact HPL(standalone board)

Thickness:0.6mm-25mm or customized thickness

Size:1220×2440mm,1220×3050mm or customized size

Pattern/Surface Finish:Wood grain,stone texture,solid color,metallic,etc.;gloss,matte,textured,etc.

Fire Rating Requirements:EN 13501-1 class(e.g.,B-s2,d0,C-s2,d0,etc.)

Application:Furniture surfacing,wall cladding,toilet partitions,laboratory worktops,marine interiors,exterior cladding,etc.

Certification Requirements:EN 438,ISO 4586,CE,etc.

Order Quantity:Pieces,pallets or container quantity

Destination Market:Destination country or port for packing and loading reference

We will provide product details,packing suggestions and quotation support as soon as possible.

Product Applications
  • 低密度轻质硫氧化镁医院净化板_-_MOS_机制面板和净化夹芯板_cleanroomequipment.en.made-in-china.com_20260626022544_region
  • 用于室内装饰的HPLPVC复合氧化镁板_-_HPL复合氧化镁板和PVC复合氧化镁_weiranbuild.en.made-in-china.com_20260626031721_region
  • 28毫米耐磨货运集装箱胶合板地板_-_集装箱地板和集装箱胶合板地板_wfsuntop.en.made-in-china.com_20260626031921_region
  • 厂家直销价整屋集装箱实木复合橡木亮面木地板_-_地板砖和建筑材料_sdluhuan.en.made-in-china.com_20260626032102_region
  • 厂家直销价整屋集装箱实木复合橡木亮面木地板_-_地板砖和建筑材料_sdluhuan.en.made-in-china.com_20260626032126_region
  • 出口级大理石纹理地坪漆，自流平车间地坪漆，户外耐磨环氧彩色砂地坪漆_-_环氧彩色_qdenze2006.en.made-in-china.com_20260626062212_region
  • 出口级大理石纹理地坪漆，自流平车间地坪漆，户外耐磨环氧彩色砂地坪漆_-_环氧彩色_qdenze2006.en.made-in-china.com_20260626062424_region
  • 出口级大理石纹理地坪漆，自流平车间地坪漆，户外耐磨环氧彩色砂地坪漆_-_环氧彩色_qdenze2006.en.made-in-china.com_20260626062524_region
  • 出口级大理石纹理地坪漆，自流平车间地坪漆，户外耐磨环氧彩色砂地坪漆_-_环氧彩色_qdenze2006.en.made-in-china.com_20260626062539_region
  • 环氧彩色砂面地坪漆，大理石纹理室内住宅防水防滑水泥地坪漆，自流平地坪漆_-_20_qdenze2006.en.made-in-china.com_20260626063146_region
FAQ
Q：

What types of paints/coatings do you offer,and which substrates are they suitable for?

A：
We provide comprehensive coating systems for various building boards,including water-based eco-coatings,fire-retardant coatings,and anticorrosion coatings.They can be customised according to different substrates(fibre cement,magnesium oxide,calcium silicate,etc.)and application environments(indoor,outdoor,humid conditions).
Q：

What are the features of Container Flooring HPL?

A：
HPL(High-Pressure Laminate)container flooring is made from multiple layers of kraft paper impregnated with thermosetting resin and combined with a decorative layer.It offers high abrasion resistance and high scratch resistance.Typical construction is plywood substrate with HPL overlay,thickness range 6-35mm,and sizes can be customised.
Q：

What is the fire rating and fire resistance limit of Magnesium Oxide Board?

A：
Magnesium Oxide Board achieves the highest non-combustible A1grade–it does not burn at 800°C,shows no flame at 1200°C,and has an ignition point as high as 2700°C.When used with quality steel framing,the partition system can achieve a fire resistance of over 3 hours.A 6mm board provides sound insulation of approximately 29dB.
Q：

What are the unique advantages of Fiber Reinforced Calcium Silicate Board?

A：
These boards are cured by steam or high-pressure steam to form a stable structure mainly composed of tobermorite crystals.They are lightweight,high-strength,fireproof,moisture-proof,heat-insulating,and have low deformation rates.Thicknesses of 5-12mm are suitable for interior partition walls and ceilings,while 18mm+boards are used for loft flooring and raised access floors for underfloor heating systems.
Q：

What specifications and densities are available for Fiber Cement Board?

A：
Standard sizes are 2000-2440mm in length and 1000-1220mm in width,with common thicknesses of 4-12mm(customisable from 2.5mm to 90mm in China).They are classified into high,medium,and low density–higher density and thicker boards provide better thermal and acoustic insulation.Products meet JC/T 412.1-2018 and JC/T 412.2-2018,with non-combustible A-grade,corrosion resistance,and electrical insulation properties.
Q：

What is the difference between Magnesium Oxysulfate Board and ordinary Magnesium Oxide Board?

A：
Magnesium Oxysulfate Board uses magnesium sulfate as the cementitious material,while traditional Magnesium Oxide Board(chloride-type)uses magnesium chloride.The biggest advantage of Magnesium Oxysulfate Board is that it does not absorb moisture or cause halogenation–chloride ions in chloride-type boards are hydrophilic and can attract moisture from the air under humid conditions,causing surface droplets and corrosion to metal.The sulfate type avoids these issues,offering excellent fire resistance,light weight,corrosion resistance,high dimensional stability,and low alkalinity.The industry standard for this product was finalised in 2021.
Q：

What is the substrate of Inorganic Pre-coated Board,and how ecofriendly is it?

A：
Inorganic Pre-coated Board is based on 100%asbestos-free calcium silicate board,which is then surface-treated and precision-coated.It contains no formaldehyde,no asbestos,and no radioactive elements,making it a green building material.In 2020,it was recognised as a Green Design Product by the Ministry of Industry and Information Technology(5th batch).
